Tripropylene glycol

CAS 24800-44-0  ·  C9H20O4  ·  MW 192.25 g/mol

Full record: Tripropylene glycol — Safety Data Sheet →

Loading molecule...
3D model Tripropylene glycol, CAS 24800-44-0, molecular formula C9H20O4, molar mass 192.25 g/mol

Model views

  • Tripropylene glycol (CAS 24800-44-0) – ball-and-stick 3D model, MolGod Viewer
    ball-and-stick 3D model
  • Tripropylene glycol (CAS 24800-44-0) – skeletal 3D model, MolGod Viewer
    skeletal 3D model
  • space-filling 3D model – rotation animation
  • Tripropylene glycol (CAS 24800-44-0) – 2D structure, MolGod Viewer
    2D structure

© 2026 MolGod.org. All rights reserved. · Image rights

🖨️ 3D print model & licenseMolGod_Print3D_1
Tripropylene glycol, C9H20O4, CAS 24800-44-0 - 3D molecular model
© MolGod.org — All rights reserved · image rights

MG_385-133-915-79 · engraved · 538,160 △ · 26 MB · SHA-256 3cd00dea138e4053

Download 3D model: Tripropylene glycol, C9H20O4, CAS 24800-44-0 · ENGRAVED (C, H, O) · 26 MB

Tripropylene glycol (CAS 24800-44-0), C9H20O4 - 3D ball-and-stick molecular model, MolGod STL previewDownload image

MG_385-133-915-79 · normal · 13,632 △ · 666 KB · SHA-256 8e2c8db61f5a4120

Download 3D model: Tripropylene glycol, C9H20O4, CAS 24800-44-0 · NORMAL · 666 KB

License & provenance ↓

⚠️ The MolGod.org name and logo, including the raised logo on the base, are our trademark. The CC BY-SA 4.0 licence does not cover trademarks (section 2(b)(2)). Do not use the MolGod.org logo to brand your own products, in advertising, or in any way that suggests our endorsement without our written permission.

About Tripropylene glycol

Tripropylene glycol is a chemical compound registered under number CAS 24800-44-0, with the molecular formula C9H20O4, and a molar mass of 192.25 g/mol.

The molecule contains 33 atoms connected by 32 chemical bonds. The full systematic IUPAC name of this compound is 2-[2-(2-hydroxypropoxy)propoxy]propan-1-ol. The interactive 3D model above lets you view the spatial arrangement of the atoms — you can rotate it with the mouse, zoom with the scroll wheel, and switch between skeletal / Ball & Stick / Space Fill visualization modes.

In terms of physicochemical properties, polar surface area PSA = 58.9 Ų, 2 donors and 4 hydrogen bond acceptors. These parameters are key when assessing bioavailability and interaction with biomolecules.

Chemical data for this compound comes from PubChem (NIH NLM NCBI), one of the world's largest chemical databases. All information is updated automatically and enriched with GHS hazard statement translations compliant with the CLP Regulation (EC 1272/2008). The interactive 3D model and the viewer images are protected by copyright (© MolGod.org) — terms of use: molgod.org/copyright/.

Physicochemical properties
Molecular formulaC9H20O4
Molar mass192.25 g/mol
IUPAC2-[2-(2-hydroxypropoxy)propoxy]propan-1-ol
SMILESCC(CO)OCC(C)OCC(C)O
InChIKeyLCZVSXRMYJUNFX-UHFFFAOYSA-N
logP (XLogP3)—
PSA58.9 Ų
HBD / HBA2 / 4
PubChem CIDCID 32611 ↗
Scientific literature

Related literature

2 articles · 0 open access · Sources: PubMed, OpenAlex, Semantic Scholar

Filters:Export:📄 BibTeX📑 RIS📋 EndNote🔧 CSL-JSON

📈 Publication timeline (number of articles: 2)

2004: number of articles 120042012: number of articles 12012

Bar height = number of articles in a given year. Hover over a bar to see details.

Data from PubMed (NIH NLM), OpenAlex (CC0), Semantic Scholar (AI2). AI Summary generated by Semantic Scholar TLDR. Articles marked with require paid access.

Data sources
Related molecules
📜 License & provenanceMolGod_License_1
COMPUTED — PubChem3D · 3D conformer computed by PubChem using OMEGA; not an experimental structure.
Model
Tripropylene glycol · 24800-44-0
InChIKey
LCZVSXRMYJUNFX-UHFFFAOYSA-N
License
CC BY-SA 4.0 International
Attribution
MolGod Scientific — Tripropylene glycol (CAS 24800-44-0)
License & provenance record
Tripropylene glycol (CAS 24800-44-0) →
MolGod molecule record
Tripropylene glycol →
Source data
PubChem CID 32611 ↗
Model information
STL generated by MolGod · MolGod STL Exporter build 48804cd20b0d · generated 2026-10-14
SHA-256 (STL)
8e2c8db61f5a41202640065215a6bc6f242fd6f52ec3a2ae46db615f4d4c3871
MD5 (STL)
536ba516f06b4948e5118f91e05aa724
MolGod Identification Number
MG_385-133-915-79
Transformation
MolGod Scientific ball-and-stick mesh
Changes
Converted into a triangulated molecular mesh; atomic coordinates and connectivity unchanged.
Wikimedia Commons
not published yet
Free printable molecule model
Download the model, print it and use it in education. When you publish a photo, a material or an adaptation, the CC BY-SA 4.0 International licence requires you to credit “MolGod Scientific” as the author of the model, link to the original and to the licence text, indicate any changes you made and share adaptations under the same licence. A ready-to-use attribution text is in this section. No sign-up, no fees and no obligation to leave a review.

This license applies to the MolGod-created STL mesh, not automatically to third-party source material.

—
